Application

ASSA Key in Knob/Key in Lever cylinders are manufactured to exact manufacturers’ specifications to ensure precise fit and operation while providing the ultimate in high security retrofit for a variety of leading cylindrical lockset manufacturers.

Benefits

• Two independent locking mechanisms to ensure security and optimum pick resistance
• Inactive “false” grooves on side pins designed to increase pick resistance
• Counter mill in each chamber position to further enhance pick resistance
• Extremely close tolerances
• Can be easily rekeyed in the field
• Patented key control

Technical Information

• Available in 15 different retrofit assemblies
• Cylinder shell and plug made of high quality brass
• Stainless steel top pins
• Bottom pins and master pins are nickel silver

Surface treatment

• Satin Chrome (213)
• Polish Chrome (211)
• Polish Brass (220)
• Satin Brass (221)
• Brown oxid (044)

Warranty

ASSA warrants its cylinders against defective workmanship or wear under normal use and with regular maintenance.
