• ELECTRICAL DATA

    Power supply V DC: 12-24, supplied by control unit
    Consumption Watts min. 0,24 max. 0,32 at 24 V
    Amp: min. 0,010 max. 0,013 at 24 V


    ENVIRONMENT
    Temperature ˚C: -30 to +60
    Humidity % Rh: 10 to 100



    CONNECTION TO CONTROL UNIT

    Control units with programming via PC
    700XX: Yes
    MC1: Yes
    Styra 3000 Yes



    PRODUCT DATA

    Card data
    Mifare Classic 1K Yes
    Mifare Classic 4K Yes
    4 byte UID Yes
    7 byte UID No
    Reads card serial number Yes
    Reads any chosen block in optional sector Yes
    Remote upgrade from Multiaccess Styra
    via Styra 3000
    Yes



    DIMENSIONS, mm

    Height: 116
    Width: 70
    Depth:
    20
    Net weight in kg: 0,2
    Installation height (central point of cable inlet) 1270
