Apartments Security Entrance Door, RC3, EI60

Solution family: Interior Door Solutions/Exterior Door Solutions

Solution group: Single-Steel

ASSA ABLOY Poland high security solution for interior or exterior fire resistance doors, comprising of a mechanical locks with a handle sets on both sides door leaf, finished with replaceable cladding panels, by ASSA ABLOY Mercor Doors.

Door set allows to protect against burglary and unauthorized access by locking the locks with a key.

Typical application markets

Residential, Hotel, Hospitality

Specification

  • DL1.3 PP60 RAPTOR, leaf made of galvanized steel sheets 1,0mm or 0,75mm thick, four-side rebated. External cladding made of 6mm thick HDF/MDF panels. Door equipped with 4 hinges painted in RAL with 3-dimmension adjustment, includng 1 self-closing R-spring, three anti-burglary pins on the hinge side and a panoramic viewer. Mechanical strenght - 4 class according to PN-EN 1192:2001. Burglary resistance – class RC3 according to PN-EN 1627:2012. Acoustic rating - Rw=46dB according to PN-EN ISO 717-1:2013-08. Thermal transmittance - Ud = 1,3 W/m2K. Corner galvanized steel frame 1,5mm thick, equipped with fixed threshold 20 mm height.

    • Mortice lock case Monoblock 354M (mechanical), by Yale, Standard: EN 12209
    • Mortice lock case Monoblock Safety 353P (mechanical), by Yale, Standard: EN 12209
    • Euro profile cylinder Y600, by Yale, Standard: EN 1303
    • Door handles with rosette security sets, by ASSA ABLOY, Standard: EN 1906
    • Door viewer, by Yale
