• TECHNICAL CHARACTERISTICS:

    • „C” or „L” profile frame made of zinc plated steel sheet 2 mm thick with EPDM gasket on three edges
    • door leaf made of two zinc plated steel sheets 1 mm thick
    • door leaf 60 mm thick without additional finishes with EPDM gasket on four edges
    • ·filled with mineral wool of a density 60kg/m3
    • three hinges with ball bearings
    • three anti-burglary bolts
    • main lock: class 4
    • additional lock (optional)



    PARAMETERS:

    • wind load resistance – class C2 according to EN 12210: 2016-05
    • water resistance – class 4A according to EN 12208: 2001
    • acoustic insulation – Rw= 46dB according to EN ISO 717-1: 2013-08
    • thermal transmittance – 1,3 Uw(W/m2K) according to EN ISO 10077-1: 2007
    • air permeability – class 3 according to EN 12207: 2001
    • operating forces – class 3 according to EN 12217: 2005
    • mechanical strength – class 4 according to EN 1192: 2001
    • burglary resistance – class RC3 according to EN 1627: 2012



    APPLICATION:

    • residential, storage, commercial, garage facilities and technical rooms exposed to burglary
    • military, police, prison facilities where RC3 class security is required
    • facilities related to cash handling
    • power and telecommunication facilities with an average degree of protection against burglary
    • all other facilities where doors are used in average conditions
