• TECHNICAL CHARACTERISTICS:

    • „C” or „L” profile frame made of steel sheet  3mm thick reinforced with a bulletproof insert with EPDM gasket on three edges (after installation can be filled with concrete)
    • door leaf made of steel sheet 2 mm thick
    • door leaf 65 mm thick without additional finishes with EPDM gasket on four edges
    • additional bulletproof insert FB7
    • filled with mineral wool of a density 60kg/m3
    • four hinges with ball bearings
    • three anti-burglary bolts
    • main lock: multipoint class 7 according to EN 12209
    • additional lock class 7



    PARAMETERS:

    • bulletproof resistance – class FB7 according to EN 1522: 2000
    • wind load resistance – class 5C according to EN 12210: 2001
    • dangerous substances – PZH approval according to EN 14351-1+A1: 2010
    • water resistance – class 3A according to EN 12208: 2001
    • acoustic insulation – Rw= 40 dB according to EN ISO 717-1: 1999
    • air permeability – class 4 according to EN 12207: 2001
    • mechanical strength – class 4 according to EN 1192: 2001
    • burglary resistance – class RC5 according to EN 1627: 2011



    APPLICATION:

    • residential, storage, commercial, garage facilities and technical rooms of very high exposure to burglary and exposure to firing
    • security services facilities exposed to firing from sniper rifles
    • government facilities exposed to firing from sniper rifles
    • military, police and civil shooting ranges
    • military facilities requiring FB7 protection
