Height-adjustable spindle Height-adjustable spindle

Height-adjustable spindle

Offers flexibility, compensates installation mistakes and enables later adjustment without cost or time delays

Independent adjustmentsIndependent adjustments

Independent adjustments

Closing and latch speeds can be raised and lowered independently, so closing performance matches the door’s use

Backcheck as standardBackcheck as standard

Backcheck as standard

Prevents the door from slamming, reducing the risk of damage to the door, frame, or surrounding area

  • Features

    • Height-adjustable, grooved spindle and guide rail compensate installation mistakes
    • Closing and latch speeds can be raised and lowered independently
    • Durable, front-facing metal valves make adjustments easy and reliable
    • Consistent performance in a wide range of temperatures
    • Backcheck functionality as standard protects frame and surrounding areas
    • Easy to retrofit using drilling template compliant with EN 1154, supplementary sheet 1

    Accessories

    • DCFA10/DCFA11 spacer plates for shimming guide rails over ASSA ABLOY drilling pattern
    • DCFA12/DCFA13 mounting and replacement plates for mounting over ASSA ABLOY drilling pattern and over existing drill holes when the guide rail is replaced
    • A188 mechanical opening damper, continuously adjustable up to an opening angle of max. 130° (does not replace door stop)
  • DescriptionPart numberType
    DC700G-CO-FT, including DC700 + A120 for passive leaf, silver, EV1 DC700FT2--DEV1-Door closer
    DC700G-CO-FT, including DC700 + A120 for passive leaf, stainless steel design DC700FT2--D35--Door closer
    Guide rail for security door closer, double leaf, with door coordinator, 24 V DC, door width 2500 mm, silver, EV1 DCG-21-70FDEV1-Guide rail
    Guide rail for security door closer, double leaf, with door coordinator, 24 V DC, door width 2500 mm, stainless steel design DCG-21-70FD35--Guide rail
    Spacer / replacement plate set for guide rail G-CO-FT, for narrow rebate doors, 5 mm, door width 2500 mm, silver, EV1 DCFA10-----EV1-Accessory
    Spacer / replacement plate set for guide rail G-CO-FT, for wide rebate doors, 15 mm, door width 2500 mm, silver, EV1 DCFA11-----EV1-Accessory
    Mounting / replacement plate set for guide rail G-CO-FT, for narrow frames, 5 mm, door width 2500 mm, silver, EV1DCFA12-----EV1-Accessory
    Mounting / replacement plate set for guide rail G-CO-FT, for narrow frames, 15 mm, door width 2500 mm, silver, EV1 DCFA13-----EV1-Accessory
    Opening damper A188 DCA188---------Accessory
  • NameValue
    Guide rail G-CO-FT For door closer information, please see DC700G-FT and DC700.
    Closing forceEN size 3-6
    Maximum active leaf width 1200 mm
    Maximum hinge distance 1480 – 2500 mm
    Maximum opening angle~170°
    Door system Double leaf
    Handing Left- / right-handed
    Mounting options Leaf mounting on hinge side
    Force adjustment Yes
    Height adjustment Yes
    Corrosion resistance Grade 3 (96 hours)
    Dimensions (H x D x L) 31 x 61 x * mm (*depends on hinge distance)
    Escape door strike
    Holding force 2000 N
    Required power supply 24 V DC
    Rated current 95 mA / 24 V
    Rated operational voltage tolerance +/- 10 %
    Anchor contact Yes
    Free-wheeling diode Yes
    Operating temperature range -15 °C to +40 °C
    Certified in compliance withEN 1154 (door closer) | EN 1158 (coordinator) | EltVTR (escape route controller)
    CE classification 3 | 8 | 3-6 | 1 | 1 | 4
    CE / UKCA mark Yes
    Suitable for fire and smoke protection doors Yes
    Barrier-free according to CEN/TR 15894
    Third-party verified EPD ISO 14025, EN 15804
