Profile-double cylinder eCLIQ N551
One side required locking action (A), one side dummy (B) - without key
Product description
- Available as rotary secured or electronical version (V=)
- Brass cylinder housing components
- Standard finish, satin nickel-plated (OF=MV)
- Basic cylinder length 61 mm (C) - A/B (L=30/30) - other installation lengths available - flexible modular system
- Optional, differing basic cylinder length of 56 mm (C) - A/B (L=28/28)
- Standard locking cam position (SST=30°); differing locking bit position available, optionally available with SST=FLEX
- Optionally available with double locking cam (VAR=K901310-X-BIFFAR)
- Optionally available with anti drilling protection class 2 (AB=2)
- Cam made of break-proof, corrosion-resistant stainless steel
- Maintenance-free for up to 200,000 cycles
- Splash-proof IP54
- Dust and rain cover for one side available (SUR=3) IP55
- Optionally VdS★★★ (SZ=VDS-BZ+, AB=3)
- Optionally DIN EN 15684 with anti drilling protection class 2 (SZ=DIN, AB=2)
- Optionally available for use in potentially-explosive atmospheres in Zone 1 (ATEX=II 2G EX IB IIB T4 Gb)
Scope of delivery
- 1 profile-double cylinder
- 1 cylinder fixing screw M5 x 85 mm
PIV CERT
ATEX
For use in explosion-prone areas
Security Card
Order number Product
N109,V=E1 Key eCLIQ N109,V=E2 Key eCLIQ N109,V=E3 Key eCLIQ N109,V=B1/B2/B3 Key eCLIQ
N109,V=PR/PSM/PN Key eCLIQ Article number OF= (Surface) L= (Length) V= (Version) N551 MV/MV (Matt, nickel-plated) 30/30 D (Rotary secured version) MV/MV (Matt, nickel-plated) 30/30 E (Electronic version)
Special identification marking
Description Info Special designation of your choice for the front of profile cylinders, 6 characters maximum (SBZ=) per cylinder AB= Description Area of application Info -/2 Security category 2 drilling protection For profile double cylinders per side 2/2 Security category 2 drilling protection For profile double cylinders per cylinder 2/- Security category 2 drilling protection For profile double cylinders per side ATEX= Description Info II 2G Ex ib IIB T4 Gb Locking cylinders for Zone 1 hazardous areas per cylinder SZ= AB= Description Area of application Info DIN -/2 DIN-tested profile cylinder For profile double cylinders per side DIN 2/2 DIN-tested profile cylinder For profile double cylinders per cylinder VDS -/3 VdS-approved profile cylinder For profile double cylinders per side VDS 3/- VdS-approved profile cylinder For profile double cylinders per side DIN 2/- DIN-tested profile cylinder For profile double cylinders per side VDS 3/3 VdS-approved profile cylinder For profile double cylinders per cylinder OF= Area of application Info MC For profile and locking lever cylinders per cylinder MP For profile and locking lever cylinders per cylinder MV For profile and locking lever cylinders per cylinder MG For profile and locking lever cylinders per cylinder ../.. For profile double and knob cylinders per cylinder SUR= Area of application Info 3/- For profile double cylinders per side -/3 For profile double cylinders per side Installation lengths of double and knob cylinders
=28/28
=28/30
=28/35
=28/40
=28/45=30/28
=30/30
=30/35
=30/40
=30/45
=30/50
=30/55
=30/60
=30/65
=30/70
=30/75
=30/80=35/28
=35/30
=35/35
=35/40
=35/45
=35/50
=35/55
=35/60
=35/65
=35/70=40/28
=40/30
=40/35
=40/40
=40/45
=40/50
=40/55
=40/60
=40/65
=40/70=45/28
=45/30
=45/35
=45/40
=45/45
=45/50
=45/55
=45/60
=45/65
=50/30
=50/35
=50/40
=50/45
=50/50
=50/55
=50/60
=55/30
=55/35
=55/40
=55/45
=55/50
=55/55
=60/30
=60/35
=60/40
=60/45
=60/50
=65/30
=65/35
=65/40
=65/45
=70/30
=70/35
=70/40
=75/30
=75/35
=80/30Downloads for Product
