• Suitability

    • Suitable for use on sashes with a maximum width of 1800mm and pushing force of 18kg.
    • Suitable for awning or casement windows.
    • Elevation Actuators are only to be used on windows with hinges or non-friction stays.

    Fixing Surfaces

    • Timber
    • Aluminium

    Voltage
    24V DC

    Maximum Current Draw

    • Actuator = 750mA
    • Keypad = 100mA
    • Rain Sensor + Network Adaptor = 350mA
    • Wall Switch + Network Adaptor = 100mA

    Operating Force
    Opening/Closing Force 90N

    Stroke Length
    Maximum Opening Stroke 300mm

    Stroke Time
    Closing time approximately 40 seconds

    Environment
    0 to 50° Celsius
    0-95% Humidity

    Chain
    Stainless Steel (Grade 302)

    Finish Options
    Black, P Colours or Special
