• User Interface

    LCD Touchscreen
    LCD TFT Colour Display with 2.4" (320x240) resistive touch screen

    Embedded Web Software
    Complete access control management from your browser

    Access Control

    Door Control
    1 door with REX button and door sensor inputs

    User Capacity
    More than 200.000 registered users

    Fingerprint Capacity
    Up to 6.000 fingerprints in standalone

    Access Rules
    Customized by time, group and department

    Transaction Log Capacity
    Over 200.000 records

    iDCloud
    Cloud monitoring, synchronization and backup. Sold separately.

    I/Os
    1 relay output (220VAC/5A)
    1 Wiegand input - also configurable as ABATRACK II
    1 Wiegand output - also configurable as ABATRACK II

    Communication

    Ethernet
    1 10/100Mbps Ethernet

    USB
    1 USB 2.0 Host

    RS-485
    1 RS-485 port for communication between the External Access Control module and terminal

    Modes of Identification

    Fingerprint
    500 DPI Optical Fingerprint Reader

    High Frequency Card
    13.56 MHz Mifare

    Password
    Numeric password

    General Characteristic

    Size and Dimension
    166mm x 58mm x 103mm - package dimensions
    Device weight
    212g Net Weight (terminal)/ 34g Net Weight (module)
    Power Supply
    12V (not included)



    Interconnection Diagram
