ASSA ABLOY SL300 Operator
With the SL300, never compromise on reliability.
ASSA ABLOY SL500 Operator
Automate your entrance in a variety of configurations with the ASSA ABLOY SL500 Operators
Automate your entrance in a variety of configurations with the ASSA ABLOY SL500 operators.
Designing entrances which work around your business, operation and facility is easy, even where existing doors are operational - regardless of brand. The ASSA ABLOY SL500 sliding door modular composition facilitates flexibility in every aspect, enabling you to tailor your entrances in a unique way without compromising with safety, security and sustainability.
Strong and reliable automatic sliding door operator for heavy traffic flows
In high-traffic retail, transportation and healthcare environments, where heavy-duty applications are required, the ASSA ABLOY SL500 sliding door operator is a reliable choice. The powerful yet smooth operator manage door weights up to 2x200kg or 1x240 kg and can be configured in multiple ways.
Like all our operators the ASSA ABLOY SL500 is easily managed with an intelligent touch display located either next to the door or at a remote location as far as 500 meters away. Each mode selector can operate up to five door systems at the same time.
Slim automatic sliding door operator for sleek design
Where entrance aesthetics are especially important, for example, on glass entrances in modern buildings, the ASSA ABLOY SL510 operator is a perfect choice. With a slim height of just 100 mm, a whisper-soft opening and closing experience, it blends into its surroundings for an unobstructed impression, still offering maximum performance
Telescopic automatic sliding door operator for maximum openings space.
In narrow corridors, or for small entrances that would benefit from a larger opening width, the telescopic ASSA ABLOY SL520 operator is a perfect fit. The modular ASSA ABLOY SL520 optimizes maximum opening width for all entrances. It is available for bi-parting, four-leaf and single slide two-leaf doors. It also offers a unique solution to lock all individual door leaves simultaneously for maximum security.
A perfect fit to your needs
All operators can be integrated as part of our automatic sliding door systems or be adapted to a wide range of existing doors and customer requirements. They are supplied completely assembled in the support beam, which ensures quality and also makes the operator equally easy to install as a new or replacement installation.
ASSA ABLOY SL500 operator
- 150 mm x 123 mm
- Power supply: 100 V AC -10% to240 V AC +10%;50/60 Hz
- Power consumption: max. 250 W
- Recommended max. door weight:
ASSA ABLOY SL500-2 without break-out: 200 kg/door leaf
ASSA ABLOY SL500-2 with break-out: 100 kg/door leaf
ASSA ABLOY SL500-R/L without break-out: 240 kg
ASSA ABLOY SL500-R/L with break-out: 100 kg - Clear opening width (COW)
ASSA ABLOY SL500-2 1000 – 3000 mm (bi-parting)
ASSA ABLOY SL500-1 800 – 3000 mm (single slide) - Contact local sales representative for other dimensions.
- Opening and closing speed variable up to 1.7 m/s (2 leaves)
- Hold open time: 0 – 60 s
- Ambient temperature: -20°C to +50°C
- Relative humidity(non-condensing) Max 85%
ASSA ABLOY SL520 operator
- Height x depth: 150 mm x 165 mm
- Power supply: 100 V AC -10% to 240 V AC +10%;50/60 Hz
- Power consumption: max. 250 W
- Recommended max. door weight
ASSA ABLOY SL520-2: 80 kg/door leaf
ASSA ABLOY SL520-R/L: 80 kg/door leaf - Clear opening width (COW)
ASSA ABLOY SL520-2: 17400– 4000 mm
ASSA ABLOY SL520-1: 900 – 4000 mm - Contact local sales representative for other dimensions.
- Opening and closing speed variable up to 1.7 m/s (2 leaves)
- Hold open time: 0 – 60 s
- Ambient temperature: -20°C to +50°C
- Relative humidity(non-condensing) Max 85%
ASSA ABLOY SL510 operator
- Height x depth: 100 mm x 198 mm
- Power supply: 100-240 VAC ±10% 50/60 Hz
- Power consumption: max. 250 W
- Recommended max. door weight
ASSA ABLOY SL510-2 without break-out 200 kg/door leaf
ASSA ABLOY SL510-2 with break-out 100 kg/door leaf
ASSA ABLOY SL510-1 without break-out 240 kg
ASSA ABLOY SL510-1 with break-out 100 kg - Clear opening width (COW)
ASSA ABLOY SL510-2 1000 – 3000 mm (bi-parting)
ASSA ABLOY SL510-1 800 – 3000 mm (single slide) - Contact local sales representative for other dimensions.
- Opening and closing speed variable up to 1.7 m/s (2 leaves)
- Hold open time: 0 – 60 s
- Ambient temperature: -20°C to +50°C
- Relative humidity(non-condensing) Max 85%
