Bulletproof doors NV-1

Construction:

• basic supporting structure made of steel pipes
• galvanised steel sheet metal lining, no finishing paint
• finish lining – standard aluminium profile 70 and 104 mm
• other parts, sheet thickness up to 4 mm
• internal reinforcements

Design: ballistic resistance, class 3 (Magnum 357)

Type designations: NV-1/KL-3

Finishing: plasticised in RAL colours

Gaskets: in door jamb (three-sided) rubber, black

Fittings:

• door lock DIN 18250 (central)
• ball bearing joint (2 pcs)
• fire door handle with round rosette – stainless steel • rosette for cylinder and handle, oval, separated – stainless steel
• cylinder with three keys (standard or with wheel)
• hydraulic door closer for fire door EN 1154
• automatic door bolt in secondary leaf-top

Glazing:

•  armoured glass, ballistic resistance class BR3 (Magnum 357) certified in compliance with EN 1063 standard
• panel, ballistic resistance class BR3

Installation:

• on finished wall, vertical reinforced concrete tie beams
• threshold on the floor is necessary

Tested: IGH - Zagreb
