Key eCLIQ N109,V=E2 | ASSA ABLOY

Overview of Advantages

Ideal in combination with the wall programming devices and the mobile programming device

Product description

Electronic key-unique and locking system encryption
Additionally with time function and event memory for the last 100 locking actions
Ideal in combination with the wall programming devices and the mobile programming device
LED indicator and acoustic signalling for functional operation and battery status
The data and power transmission to the cylinder is contact based
The data transmission to the cylinder is highly encrypted
Temperature range 0° C to +70° C
Protected against temporary immersion in water (IP67)
Powered by commercially-available lithium battery (CR2450)
For 100,000 locking operations (service life of about 10 years)
The battery can be easily changed by the user without tools
Standard colour for battery cover: black (RD=SW)
Other colours for battery cover: blue (RD=BL), yellow (RD=GE), green (RD=GN), grey (RD=GR), red (RD=RT) and orange (RD=OR)

Optionally available with a RFID tranponderchip (AUS=LEGICPRIME, AUS=LEGIC ADVANT, AUS=MIFARE CLASSIC, AUS=MIFARE DESFIRE EV1, AUS=MIFARE DESFIRE EV2, AUS=EM4102, AUS=HITAG 1 or AUS=HITAG 2) integrated in the battery cover

Optionally available for use in potentially-explosive atmospheres in Zone 1 (ATEX=II 2G EX IB IIB T4 Gb)

Scope of delivery

1 electronic user key, including battery

Note

The key can be adjusted when ordering or later by a colored battery cover or a transponder battery cover (NZ02)
