N482
Product description
- Available as rotary secured or electronical version (V=)
- Brass cylinder housing components
- Standard finish, satin nickel-plated (OF=MV)
- Basic cylinder length of 30 mm (A) (L=30) - Other installation lengths available - Adaptable housing kit
- Standard locking cam position (SST=8x45); differing locking cam position (SST=12x30) available
- Standard with rigid connection VAR=STARR and free adjustable locking cam SST=FLEX
- Optional with SST=FZG possible
- Free-wheeling function only without VAR=STARR
- Optionally available with anti drilling protection class 2 (AB=2)
- Cam made of break-proof, corrosion-resistant stainless steel
- Maintenance-free for up to 200,000 cycles
- Splash-proof IP54
- Dust and rain cover available (SUR=1) IP55
- Optionally available for use in potentially-explosive atmospheres in Zone 1 (ATEX=II 2G EX IB IIB T4 Gb)
Scope of delivery
- 1 cylinder fixing screw M5 x 85 mm
