• Certifications:

    • FCC Part 15 & Industry Canada Compliant
    • CE RED – Radio Equipment Directive – 2014/53/EU
    • RoHS Compliant

    Electrical:

    • Estimated Battery Life: 50,000 Cycles
    • (2) “AA” lithium batteries (included)
      • AA Lithium Batteries required. Use of other types of batteries, such as alkaline, will significantly decrease battery life.
      • Battery voltage monitoring
      • microUSB port for emergency power

    Holding Force:

    • Static strength 350 lbs

    Environmental:

    • Operating Temperature: 32 to 122 F (0 to 50 C)
    • Tested to meet IP54

    Card Technology HID® multiCLASS SE®

    High Frequency (13.56 MHz)

    -   HID iCLASS®

    -   HID iCLASS SE (SIO-enabled)

    -   HID iCLASS® Seos

    -   HID MIFARE® SE

    -   HID DESFire® EV1 SE

    -   MIFARE CLASSIC

    -   DESFire® EV1

    Low Frequency (125 kHz)

    -   HID Prox®

    -   AWID

    -   EM4102

    -   ioProx

    NFC-enabled Mobile Phones

    Features

    Standard Features

    • For use with cam-activated swing handle server cabinet applications with a 150 x 25 mm lock prep
    • 2.4 GHz Aperio wireless technology
    • Supports HID multiCLASS SE® card technologies
    • Integrates with existing access control systems and ID badges
    • Audit trail limited by EAC system
    • LEDs indicate valid/invalid entries; Red/Amber or Green/Amber
    • Integrated locked state (handle), cam rotation and tamper monitoring
    • Automatic relock
    • Non-handed
    • Black finish
    • SecuriCare three-year, no fault, no questions asked warranty

    Optional Features

     Supports 6 or 7-pin SFIC mechanical key override (sold separately)

    -   __ (blank), NO SFIC or blank plastic core (standard)

    -   BC, SFIC blank, black plastic core

    -   K1, MEDECO X4 SFIC Core, Keyed Differently (DGV Commercial Keyway), with 2 Keys (1 Control & 1 User Key)

    -   MK-XXXXXX, MEDECO X4 SFIC Core, Master Keyed (DGV Commercial Keyway), with 2 Keys (1 Control & 1 User Key)

    External Door Status Monitoring (KS-DPS)

    Accessories:

    • SFIC MEDECO X4 SFIC cylinder & 2 keys (1 control, 1 user)
    • SFIC-BC KS SFIC blank, black plastic core
    • KS-DPS Surface mount DPS (external)
    • KS-CAM38 CAM: 38MM-1
    • KS-CAM45 CAM: 45MM-5
    • EXT-10-ANT Aperio Hub External Antenna (Omni-directional)
