• Battery type1 x Lithium CR2
    Battery lifetime<30,000 cycles (max 2 years)
    Radio standard

    IEEE 802.15.4 (2.4GHz)

    EncryptionAES 128 Bit
    Wireless range:
    Cylinder to Hub
    5-25 m depending on location of Hub & environment
    RFID technology**MIFARE Classic®, MIFARE Ultralight®,MIFARE® DESFire®, MIFARE Plus®, MIFARE® SE, MIFARE® DESFire® SE;iCLASS SE; iCLASS Seos®, iCLASS Seos Elite
    RFID readingUID / Sektor / Block / Application / File
    Card reading range< 4cm
    Operating temperature-20° to +55°C
    Knob colourBlack / Satin Chrome
    Cylinder ColourSatin Chrome
    Cylinder formatLockwood Australian Oval 570, 201 Rim and 8466 Kawneer series Cylinders
    Door thicknessSuits standard doors up to 50mm
    ApprovalsCE and RCM
    StatusLED (red/green/orange)
