CY10 Cylinders and Keying
Description:
Mortise cylinder with standard American format suitable for multiple level master keying.
Areas of Application Mortise locks, exit devices, key switches and other hardware items that are operated by mortise cylinders Material Brass or Bronze Standard Keyway SC Keyway Keying Factory master keying or 0-bitted / uncombinated for end user keying Optional Keyways Other keyways available upon request Standard Length 29 mm (1-1/8”) Cams Please specify the model of the securing device in ordering information to supply suitable cam. Various options of cams available. Number of Pins 6 Pins Certifications ANSI/BHMA: Meets the requirements of ANSI A156.5-2001 Note: For use in other manufacturer securing devices,please mention the manufacturers cam number with manufacturer name prefixed for cam selection in ordering information
