ASSA ABLOY DE6090MR Manual Restraint System
Manual restraints
The ASSA ABLOY DE6090MR Manual Restraint offers the same as ASSA AABLOY DE6190AR Automatic Vehicle Restraint System functionality, except that the blocking arm for the rear wheel of the trailer is secured and released manually.
The manual system also incorporates a two-way interlocking system, meaning dock doors cannot open before the restraint system is in place and the blocking arm will only be retractable when the dock door is closed.
Prevents vehicle creep and possible drive off during the loading operation
Cannot be removed during loading operation as is mechanically blocked
Manual operation by one person
ASSA ABLOY DE6090MR Manual Vehicle Restraint System
- Product ID: DE6090MR
- Restraint force: 100kN
- Standard cable length: Motor cable 15 m, Sectional door sensor cable 2,5 m, Dock leveler sensor cable 15 m
- Traffic light: Integrated on the unit
- Interlocking: Sensor for sectional door. Sensor for dock leveler
Additional options:
- Traffic light: Additional outside with 12 m cable
- Equipment: Parking guides cast in concrete installation. Parking guides bolted installation
